Risk Ranking
Simaclim Model
Region
Khor Al Zubair ,Um Qasr Port, Khor Abdullaa
Sources
Industrial activities, Agricultural activities ,Oil spil ,Waste water plant, ,Ships , Forest ,Urban Area,contaminated Land,Golf courses
Habitat
Marsh/Wetland, River mouth/Estaury,Mud Flat, Coarse grain shore,Fjords,
Sheltered nearshore archipelago,Harbour Bays,Straights
stressors
Petrolum &Oil,Pesticides, Metals,Turbidity, Organic &Nutrient
Indicators
Chemical Water Q. , Biological Water Q , Sediment Q (Quality )
Habitat Vs Indicator Relation
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
Stressors Vs Indic.
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
Sources Vs Indic.
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
From the graphs above, we can say that the most effective contamination sourcesKhor Al-Zubair, are the industrial & agricaltural activities,Oil spil,
the site is surrondining by industries, Sheeba Refinary, chemical complex,power Plants, Fertilizers factory, many other smaller ones,(oil station ...)
There is a good agricalture activity nearby, so we can see the peticides & nitrogene in the KZ river water which effected the water quality. the waste water plant is not sufficient & competent , so we can observe a percentage of pollution in it s output water.
Dusty winds & tides are good transporters , Runoff as well
Oil pollution is remarkable( many oil feilds around , which effected the water &Sediments as well ,
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
The application of two dimensional model on oil spill movement in Khor ALZubair, north west, Arabian Gulf Samer A. R. Al-Taei1 , Abdul R. H. Subber2 and Faris J. M. Al-Imara
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
Assessment of hydrocarbons and trace metals pollution in water and sediments of the Fertilizer Plant wastes in Khor Al-Zubair, Iraq A.W.A. Sultan¹, A.A. Alhello², M.A. Aribi³ and H.T. Al-Saad²
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
Um Qasr port is polluted because of Shipping , Oil, Urban Area,the industrial activity is not one of the main sources,the harbour is one of the most active &busy ports for oil ships-Tanker in the world.
Dusty winds & tides are good transporters , Runoff as well
​
​
​
Khor Abdulla is the river mouthto the Arbian (persian ) gulf. oil spil +shipping are the main pollution sources, no industry & agriculture available around, the sea currents play important role as pollution transporter
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
​
OOBS
Some Zero value in the graphes,represnt unavailable data,not the real statestics facts.
